Description
Areca ARC-8050T5U-12E (12 Bay Thunderbolt 5 / USB 3.2 Gen 2 Type C RAID Enclosure)
Mac Systems: Thunderbolt 5 on Mac requires macOS 15.3 Sequoia or later
Windows Systems: Windows PCs supporting Thunderbolt 5 require Windows 11 (version 23H2 or later) and hardware Thunderbolt 5 compatibility (such as Intel's latest Core Ultra series processors).
The ARC-8050T5U series are equipped with dual Thunderbolt 5 ports for connecting to any Thunderbolt 5 enabled host and offers an additional Thunderbolt 5 port for daisy-chaining other peripherals, while also supplying power for quick notebook charging. The ARC-8050T5U also sports a full sized DisplayPort 2.1 MF video output on its rear, allowing for a quick and easy dual 6K display setup.
If an ARC-8050T5U is plugged in a USB-C computer port, a USB device controller inside the ARC-8050T5U-enabled system is activated, and the inside USB device controller drives USB 3.2 Gen 2 signals to the USB-C port. In this condition, the ARC-8050T5U Thunderbolt 5 port behaves exactly like a typical USB-C 3.2 Gen 2-enabled connector.
True Hardware RAID Controller
At the heart of ARC-8050T5U 4/6/8/12-bays RAID storage is the incredibly powerful Raid-on-Chip (ROC) storage controller, giving effortless performance as desirable. It delivers true hardware RAID function without sharing the CPU computing power on the host system and also eases off CPU loading as compared to software RAID and when rebuilding an array in the event of a drive failure.
High-Speed On-Board Cache
With a massive on-board high speed SDRAM, ARC-8050T5U gives you super-smooth multitasking during the period of high overload in 8K environment. ARC-8050T5U can configure how much cache SDRAM dedicated for read, and how much for write. If your server application has significantly more reads than writes or more writes than reads, you might need to change this setting to adjust the read/write cache ratio for improving performance. Big cache is the perfect choice for a 4K application drive, making your professional apps work as fast as possible.
- High performance 80 and 120 Gbps Thunderbolt 5 interface
- Support simultaneous Dual 6K in/output workflow
- Support a USB-C computer port
- Fully support Apple silicon on Macs
- Configuration by the Thunderbolt/LAN port/LCD
- 1m 120 Gbps active Thunderbolt™ 5 (USB-C) cable included
- Advanced configuration for video optimized performance settings
- Delivers enterprise-class data protection and security
- Controller-level hardware encryption
- Intelligent power On/Off function for data integrity
- SED (self-encrypting drives) function support
- Hard drive firmware update all at once
